Rafeed - E-Series - Recessed Panel Downlight

Catalogue

Product view

Recessed

Description

Lena’s family, the new version of Slim Downlight.

It is Characterized by its aluminum body and milky diffuser. It comes in multiple sizes and suitable ceiling holes.

Family Technical Data

Model	Power	CCT	CRI	IP	Beam Angle	Controls and Dimming	Luminous flux	Color
LE30337	9 W	3000	70	20	180	not dimmable	758 lm	White White
LE40338	9 W	4000	70	20	180	not dimmable	758 lm	White White
LE60339	9 W	6000	70	20	180	not dimmable	758 lm	White White

Model	Power	CCT	CRI	IP	Beam Angle	Controls and Dimming	Luminous flux	Color
LE30340	18 W	3000	70	20	180	not dimmable	1440 lm	White White
LE40341	18 W	4000	70	20	180	not dimmable	1440 lm	White White
LE60342	18 W	6000	70	20	180	not dimmable	1440 lm	White White

Model	Power	CCT	CRI	IP	Beam Angle	Controls and Dimming	Luminous flux	Color
LE30343	36 W	3000	70	20	180	not dimmable	3100 lm	White White
LE40344	36 W	4000	70	20	180	not dimmable	3100 lm	White White
LE60345	36 W	6000	70	20	180	not dimmable	3100 lm	White White

Application

Offices, Hospitals & Clinics, Supermarkets, Schools, Showrooms, Government institutions, Restaurants, Hotel
